33kv Overhead Line Project Electric Power Pole Galvanised Steel Poles
|
Material: |
high quality Q345 hot rolled steel |
|
Mounting Height: |
3-30m or according to the requirements of customers |
|
Shape of pole: |
Round,conical,octagonal,square,mid hinged,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine
|
|
Brackets: |
Single or double brackets are in the shape and dimension as per customers requirement |
|
Base plate: |
Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement
|
|
Groung mounted: |
The length buried underground as per customers requirement
|
|
Galvanizing:
|
Hot dip galvanization with thickness of 80-100µm average
|
|
Powder coating: |
Pure polyester powder painting, color is optional |
Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All the purpose is to produce good quality steel poles.
The fabrication process as cutting plate, bending, forming, automatic welding, drill holes, quality checked before galvanized, hot dip galvanized and powder coating, finally quality checked according to client's requirements.
The power pole of our company are made from quality sheets through bending,forming, automatic welding, hot dip galvanization and powder coating. We owned advanced production-line, it included Flatting machine, Steel plate shearer, bending machine,Auto-closed up machine, submerged arc welding machine and powder coating line, and our workmanship and quality control was achieved high opinion from our clients.
Features:
1) Designed or improved for various kinds of power pole.
2) Material: Hot rolled steel(Q235,Q345,Q450).
3) Appearance:Hot dip galvanized or spray plastic or others(up to customer’s request).
4)Packing: Woven bag, Plastic bulble paper or Black blanket or others.
5) Shape: Octagonal, Polygonal or Tapered round.
6) Length: up to customer' request.
7) Thickness of bending plate: 2.5mm - 20mm.
8) welding:automatic.
9)Other features: Short construction cycle, less land occupation, low overall cost and easy maintenance.
